Flexible pipe coupling absorbing vibrations and axial movements in pipeline systems.

• Nominal size: DN65
• Pressure: PN10
• Material: EPDM rubber
• Connection: Clamp
• Temperature: −15…+90 °C
• Medium: Water
• Standard: EN 14525
• Weight: 1.1 kg

Y-strainer protecting downstream equipment from debris in liquid pipelines.

• Nominal size: DN32
• Pressure: PN16
• Material: Cast iron
• Connection: Flanged
• Temperature: 0…+120 °C
• Medium: Water, oil
• Standard: EN 736
• Weight: 2.3 kg

Expansion joint compensating thermal expansion and misalignment in piping systems.

• Nominal size: DN100
• Pressure: PN6
• Material: EPDM / steel
• Connection: Flanged
• Temperature: −10…+100 °C
• Medium: Water
• Standard: EN 14525
• Weight: 3.6 kg

Angle seat valve actuated for automated flow control in process installations.

• Nominal size: DN15
• Pressure: PN16
• Material: Stainless steel
• Connection: Threaded
• Temperature: −10…+185 °C
• Medium: Steam, water
• Standard: EN 13709
• Weight: 0.9 kg

Diaphragm valve for hygienic applications in food, pharma and chemical industries.

• Nominal size: DN25
• Pressure: PN10
• Material: PP / EPDM
• Connection: Flanged
• Temperature: 0…+80 °C
• Medium: Chemicals
• Standard: EN 13136
• Weight: 1.2 kg

Needle valve offering fine flow adjustment in instrumentation and hydraulic lines.

• Nominal size: DN6
• Pressure: PN250
• Material: Stainless steel
• Connection: Compression
• Temperature: −40…+230 °C
• Medium: Gas, oil
• Standard: EN 13709
• Weight: 0.3 kg

Solenoid valve for automated on/off control of water and neutral gases.

• Nominal size: DN20
• Pressure: PN10
• Material: Brass
• Connection: Threaded
• Temperature: −10…+80 °C
• Medium: Water, air
• Voltage: 24 V DC
• Weight: 0.6 kg

Motorised ball valve with actuator for remote open/close control via BMS.

• Nominal size: DN32
• Pressure: PN16
• Material: Brass
• Connection: Threaded
• Temperature: −20…+120 °C
• Medium: Water
• Voltage: 230 V AC
• Weight: 1.4 kg

Float valve maintaining constant liquid levels in tanks and cisterns automatically.

• Nominal size: DN15
• Pressure: PN10
• Material: Brass / PP
• Connection: Threaded
• Temperature: 0…+60 °C
• Medium: Water
• Standard: EN 13076
• Weight: 0.5 kg

Steam trap discharging condensate while preventing live steam loss in heating systems.

• Nominal size: DN20
• Pressure: PN16
• Material: Stainless steel
• Connection: Threaded
• Temperature: up to 200 °C
• Medium: Steam
• Standard: EN 27828
• Weight: 0.8 kg

Pressure reducing valve maintaining constant downstream pressure regardless of flow.

• Nominal size: DN25
• Pressure: PN25
• Material: Bronze
• Connection: Threaded
• Temperature: 0…+80 °C
• Medium: Water
• Standard: EN 1567
• Weight: 1.0 kg

Air release valve automatically expelling trapped air from water supply pipelines.

• Nominal size: DN50
• Pressure: PN16
• Material: Cast iron
• Connection: Flanged
• Temperature: 0…+60 °C
• Medium: Water
• Standard: EN 1074-4
• Weight: 2.5 kg
